| 型號(點擊查看詳細) | 流量(m3/h) | 揚程 | 泵效率 (%) | 軸功率 (kW) | 轉速 | 葉輪外徑 |
| 50WL(I)15-8-0.75 | 15 | 8 | 52 | 0.629 | 2825 | 95 |
| 50WL(I)15-12-1.1 | 15 | 12 | 52 | 0.943 | 2825 | 105 |
| 50WL(I)15-16-1.5 | 15 | 16 | 52 | 1.258 | 2840 | 125 |
| 50WL(I)15-22-2.2 | 15 | 22 | 52 | 1.729 | 2840 | 135 |
| 50WL(I)15-30-3 | 15 | 30 | 50 | 2.452 | 2880 | 158 |
| 50WL(I)25-25-4 | 25 | 25 | 48 | 3.548 | 2880 | 162 |
| 50WL(I)25-32-5.5 | 25 | 32 | 48 | 4.542 | 1440 | 308 |
| 50WL(I)25-36-7.5 | 30 | 36 | 48 | 6.131 | 1440 | 315 |
| 65WL(I)30-10-2.2 | 30 | 10 | 62 | 1.318 | 1420 | 200 |
| 65WL(I)30-15-3 | 30 | 15 | 62 | 1.978 | 1420 | 230 |
| 65WL(I)30-22-4 | 30 | 22 | 52 | 3.459 | 1440 | 260 |
| 65WL(I)30-30-5.5 | 30 | 30 | 52 | 4.716 | 1440 | 308 |
| 65WL(I)30-35-7.5 | 30 | 35 | 50 | 5.722 | 1440 | 315 |
| 80WL(I)50-8-2.2 | 50 | 8 | 60 | 1.817 | 1420 | 185 |
| 80WL(I)50-10-3 | 50 | 10 | 60 | 2.271 | 1420 | 205 |
| 80WL(I)50-15-4 | 50 | 15 | 58 | 3.524 | 1440 | 230 |
| 80WL(I)50-20-5.5 | 50 | 20 | 55 | 4.955 | 1440 | 260 |
| 80WL(I)50-25-7.5 | 50 | 25 | 55 | 6.193 | 1440 | 275 |
| 80WL(I)50-35-11 | 50 | 35 | 55 | 8.67 | 2900 | 185 |
| 80WL(I)50-40-15 | 50 | 40 | 52 | 10.481 | 2900 | 205 |
| 100WL(I)80-7-3 | 80 | 7 | 64 | 2.384 | 1420 | 205 |
| 100WL(I)80-10-4 | 80 | 10 | 64 | 3.406 | 1440 | 210 |
| 100WL(I)80-13-5.5 | 80 | 13 | 64 | 4.428 | 1440 | 235 |
| 100WL(I)80-18-7.5 | 80 | 18 | 64 | 6.131 | 1440 | 270 |
| 100WL(I)80-24-11 | 80 | 24 | 64 | 8.175 | 2900 | 185 |
| 100WL(I)80-32-15 | 80 | 32 | 58 | 12 | 2900 | 195 |
| 100WL(I)80-36-18.5 | 80 | 36 | 55 | 14.269 | 2900 | 200 |
| 100WL(I)80-40-22 | 80 | 40 | 55 | 15.855 | 2900 | 208 |
| 150WL(I)150-7-5.5 | 150 | 7 | 72 | 3.974 | 1440 | 200 |
| 150WL(I)150-10-7.5 | 150 | 10 | 72 | 5.677 | 1440 | 225 |
| 150WL(I)150-15-11 | 150 | 15 | 72 | 8.516 | 1460 | 230 |
| 150WL(I)150-20-15 | 150 | 20 | 68 | 12 | 1460 | 260 |
| 150WL(I)150-25-18.5 | 150 | 25 | 68 | 15 | 1470 | 295 |
| 150WL(I)150-30-22 | 150 | 30 | 65 | 18.865 | 1470 | 315 |
| 150WL(I)150-40-30 | 150 | 40 | 65 | 25.154 | 1470 | 329 |
| 150WL(I)150-45-37 | 150 | 45 | 62 | 29.667 | 1470 | 380 |
| 150WL(I)150-50-45 | 150 | 50 | 62 | 33 | 1470 | 405 |
| 150WL(I)150-60-55 | 150 | 60 | 60 | 40.88 | 1470 | 425 |
| 200WL(I)300-7-11 | 300 | 7 | 74 | 7.733 | 1460 | 235 |
| 200WL(I)300-10-15 | 300 | 10 | 74 | 11 | 1460 | 250 |
| 200WL(I)300-13-18.5 | 300 | 13 | 68 | 15.629 | 1470 | 260 |
| 200WL(I)300-15-22 | 300 | 15 | 68 | 18 | 1470 | 270 |
| 200WL(I)300-20-30 | 300 | 20 | 67 | 24.403 | 980 | 400 |
| 200WL(I)300-25-37 | 300 | 25 | 67 | 30.5 | 980 | 435 |
| 200WL(I)400-27-45 | 400 | 27 | 74 | 39.77 | 1470 | 340 |
| 200WL(I)400-34-55 | 400 | 34 | 74 | 50 | 1470 | 365 |
| 200WL(I)400-40-75 | 400 | 40 | 70.5 | 61.84 | 1470 | 400 |
| 200WL(I)400-48-90 | 400 | 48 | 70.5 | 74.21 | 1470 | 420 |
| 250WL(I)400-7-15 | 400 | 7 | 69 | 11 | 1460 | 250 |
| 250WL(I)400-10-18.5 | 400 | 10 | 75 | 14.533 | 1470 | 260 |
| 250WL(I)400-13-22 | 400 | 13 | 73 | 19.411 | 1470 | 270 |
| 250WL(I)500-10-30 | 500 | 10 | 72 | 19 | 980 | 380 |
| 250WL(I)500-16-37 | 500 | 16 | 72 | 30.28 | 980 | 400 |
| 250WL(I)500-20-45 | 500 | 20 | 72 | 37.85 | 980 | 420 |
| 250WL(I)500-25-55 | 500 | 25 | 74 | 46 | 980 | 449 |
| 250WL(I)600-28-75 | 600 | 28 | 73 | 62.71 | 1480 | 350 |
| 250WL(I)600-34-90 | 600 | 34 | 73 | 76.15 | 1480 | 380 |
| 300WL(I)600-6-18.5 | 600 | 6 | 65 | 15 | 1470 | 260 |
| 300WL(I)600-7-22 | 600 | 7 | 65 | 17.608 | 1470 | 270 |
| 300WL(I)700-11-30 | 700 | 11 | 78 | 27 | 980 | 375 |
| 300WL(I)700-14-37 | 700 | 14 | 78 | 34.24 | 980 | 390 |
| 300WL(I)700-16-45 | 700 | 16 | 78 | 39.13 | 980 | 400 |
| 300WL(I)700-19-55 | 700 | 19 | 75 | 48.32 | 980 | 430 |
| 200WL(Ⅱ)300-20-30 | 300 | 20 | 67 | 24.403 | 980 | 400 |
| 200WL(Ⅱ)300-25-37 | 300 | 25 | 67 | 30.5 | 980 | 435 |
| 200WL(Ⅱ)400-27-45 | 400 | 27 | 74 | 39.77 | 1470 | 340 |
| 200WL(Ⅱ)400-34-55 | 400 | 34 | 74 | 50 | 1470 | 365 |
| 200WL(Ⅱ)400-40-75 | 400 | 40 | 70.5 | 61.84 | 1470 | 400 |
| 200WL(Ⅱ)400-48-90 | 400 | 48 | 70.5 | 74.21 | 1470 | 420 |
| 250WL(Ⅱ)500-10-30 | 500 | 10 | 72 | 19 | 980 | 380 |
| 250WL(Ⅱ)500-16-37 | 500 | 16 | 72 | 30.28 | 980 | 400 |
| 250WL(Ⅱ)500-20-45 | 500 | 20 | 72 | 37.85 | 980 | 420 |
| 250WL(Ⅱ)500-25-55 | 500 | 25 | 74 | 46 | 980 | 449 |
| 250WL(Ⅱ)600-28-75 | 600 | 28 | 73 | 62.71 | 1480 | 350 |
| 250WL(Ⅱ)600-34-90 | 600 | 34 | 73 | 76.15 | 1480 | 380 |
| 250WL(Ⅱ)600-40-110 | 600 | 40 | 70 | 93.43 | 1480 | 405 |
| 250WL(Ⅱ)600-50-132 | 600 | 50 | 70 | 116.8 | 1480 | 435 |
| 300WL(Ⅱ)700-11-30 | 700 | 11 | 78 | 27 | 980 | 375 |
| 300WL(Ⅱ)700-14-37 | 700 | 14 | 78 | 34.24 | 980 | 390 |
| 300WL(Ⅱ)700-16-45 | 700 | 16 | 78 | 39.13 | 980 | 400 |
| 300WL(Ⅱ)700-19-55 | 700 | 19 | 75 | 48.3 | 980 | 430 |
| 300WL(Ⅱ)1000-20-75 | 1000 | 20 | 82 | 66.5 | 990 | 400 |
| 300WL(Ⅱ)1000-24-90 | 1000 | 24 | 82 | 79.8 | 990 | 435 |
| 300WL(Ⅱ)1000-28-110 | 1000 | 28 | 82 | 93 | 990 | 340 |
| 300WL(Ⅱ)1000-35-132 | 1000 | 35 | 80 | 119.2 | 1480 | 365 |
| 350WL(Ⅱ)1200-6-30 | 1200 | 6 | 72 | 27.3 | 730 | 420 |
| 350WL(Ⅱ)1200-8-37 | 1200 | 8 | 75 | 34.9 | 740 | 438 |
| 350WL(Ⅱ)1100-10-45 | 1100 | 10 | 70 | 42.8 | 740 | 465 |
| 350WL(Ⅱ)1100-12-55 | 1100 | 12 | 71 | 50.7 | 740 | 474 |
| 350WL(Ⅱ)1100-16-75 | 1100 | 16 | 75 | 64 | 990 | 425 |
| 350WL(Ⅱ)1100-20-90 | 1100 | 20 | 75 | 80 | 990 | 450 |
| 350WL(Ⅱ)1100-25-110 | 1100 | 25 | 76 | 98.6 | 980 | 475 |
| 350WL(Ⅱ)1100-30-132 | 1100 | 30 | 75 | 120 | 980 | 515 |
| 350WL(Ⅱ)1100-36-160 | 1100 | 36 | 75 | 144 | 980 | 539 |
| 400WL(Ⅱ)1500-5-30 | 1500 | 5 | 72 | 28.385 | 730 | 357 |
| 400WL(Ⅱ)1500-6-37 | 1500 | 6 | 72 | 34 | 740 | 375 |
| 400WL(Ⅱ)1500-8-45 | 1500 | 8 | 80 | 40.88 | 740 | 385 |
| 400WL(Ⅱ)1500-10-55 | 1500 | 10 | 82 | 49.85 | 740 | 412 |
| 400WL(Ⅱ)1500-12-75 | 1500 | 12 | 78 | 62.88 | 990 | 357 |
| 400WL(Ⅱ)1500-15-90 | 1500 | 15 | 78 | 78.61 | 990 | 375 |
| 400WL(Ⅱ)1500-18-110 | 1500 | 18 | 78 | 94.33 | 990 | 383 |
| 400WL(Ⅱ)1500-22-132 | 1500 | 22 | 75 | 120 | 990 | 453 |
| 400WL(Ⅱ)2000-16-132 | 2000 | 16 | 80 | 109 | 990 | 450 |
| 400WL(Ⅱ)2000-20-160 | 2000 | 20 | 80 | 136.2 | 990 | 478 |
| 400WL(Ⅱ)2000-23-185 | 2000 | 23 | 80 | 156.7 | 990 | 495 |
| 400WL(Ⅱ)2000-25-200 | 2000 | 25 | 80 | 170.3 | 740 | 625 |
| 400WL(Ⅱ)2000-28-220 | 2000 | 28 | 80 | 190.8 | 740 | 650 |
| 400WL(Ⅱ)2000-32-250 | 2000 | 32 | 80 | 218 | 740 | 685 |
| 400WL(Ⅱ)2000-36-280 | 2000 | 36 | 80 | 245.2 | 740 | 710 |
| 450WL(Ⅱ)2200-10-90 | 2200 | 10 | 72 | 83.26 | 990 | 357 |
| 450WL(Ⅱ)2200-12-110 | 2200 | 12 | 72 | 100 | 990 | 382 |
| 450WL(Ⅱ)2200-15-132 | 2200 | 15 | 75 | 120 | 990 | 410 |
| 500WL(Ⅱ)2000-7-55 | 2000 | 7 | 76 | 50.2 | 740 | 408 |
| 500WL(Ⅱ)2200-8-75 | 2200 | 8 | 70 | 68.5 | 980 | 362 |
| 500WL(Ⅱ)3000-11-132 | 3000 | 11 | 75 | 119.9 | 740 | 501 |
| 500WL(Ⅱ)3000-13-160 | 3000 | 13 | 75 | 141.7 | 745 | 531 |
| 500WL(Ⅱ)3000-15-185 | 3000 | 15 | 70 | 175.2 | 745 | 543 |
| 500WL(Ⅱ)3000-16-200 | 3000 | 16 | 72 | 181.7 | 745 | 555 |
| 500WL(Ⅱ)3000-18-220 | 3000 | 18 | 75 | 196.2 | 745 | 578 |
| 500WL(Ⅱ)3000-21-250 | 3000 | 21 | 77 | 223 | 745 | 608 |
| 500WL(Ⅱ)3000-24-280 | 3000 | 24 | 77 | 254.8 | 745 | 635 |
| 600-WL(Ⅱ)2500-5-55 | 2500 | 5 | 72 | 47.31 | 590 | 408 |
| 600WL(Ⅱ)2500-7-75 | 2500 | 7 | 75 | 63.58 | 590 | 415 |
| 600WL(Ⅱ)25000-9-90 | 2500 | 9 | 75 | 81.75 | 590 | 438 |
| 600WL(Ⅱ)3000-8-110 | 3000 | 8 | 75 | 87.2 | 590 | 565 |
| 600WL(Ⅱ)3000-10-132 | 3000 | 10 | 75 | 109 | 590 | 608 |
| 600WL(Ⅱ)4000-10-160 | 4000 | 10 | 75 | 145.3 | 745 | 502 |
| 600WL(Ⅱ)4000-11-185 | 4000 | 11 | 75 | 160 | 745 | 518 |
| 600WL(Ⅱ)4000-12-200 | 4000 | 12 | 72 | 181.7 | 745 | 534 |
| 600WL(Ⅱ)4000-14-220 | 4000 | 14 | 75 | 203.5 | 745 | 562 |
| 600WL(Ⅱ)4000-16-250 | 4000 | 16 | 78 | 223.6 | 745 | 600 |
| 600WL(Ⅱ)4000-18-280 | 4000 | 18 | 77 | 254.8 | 745 | 623 |
| 600WL(Ⅱ)4000-20-315 | 4000 | 20 | 80 | 272.5 | 740 | 645 |
