上海連成GDL系列立式多級泵規格型號及參數表

發布時間：2024-03-13人氣：1307


型號(點擊查看詳細)	流量(m3/h)	揚程	泵效率 (%)	軸功率 (kW)	轉速	葉輪外徑	級數
25GDL2-12×3	2	36	30	0.654	2950	110	3
25GDL2-12×4	2	48	30	0.872	2950	110	4
25GDL2-12×5	2	60	30	1.09	2950	110	5
25GDL2-12×6	2	72	30	1.308	2950	110	6
25GDL2-12×7	2	84	30	1.526	2950	110	7
25GDL2-12×8	2	96	30	1.744	2950	110	8
25GDL2-12×9	2	108	30	1.962	2950	110	9
25GDL2-12×10	2	120	30	2.18	2950	110	10
25GDL2-12×11	2	132	30	2.398	2950	110	11
25GDL2-12×12	2	144	30	2.616	2950	110	12
25GDL4-11×3	4	33	40	0.899	2950	110	3
25GDL4-11×4	4	44	40	1.199	2950	110	4
25GDL4-11×5	4	55	40	1.499	2950	110	5
25GDL4-11×6	4	66	40	1.798	2950	110	6
25GDL4-11×7	4	77	40	2.098	2950	110	7
25GDL4-11×8	4	88	40	2.398	2950	110	8
25GDL4-11×9	4	99	40	2.698	2950	110	9
25GDL4-11×10	4	110	40	2.998	2950	110	10
25GDL4-11×11	4	121	40	3.297	2950	110	11
25GDL4-11×12	4	132	40	3.597	2950	110	12
25GDL4-11×13	4	143	40	3.897	2950	110	13
40GDL6-12×3	6	36	51	1.154	2950	110	3
40GDL6-12×4	6	48	51	1.539	2950	110	4
40GDL6-12×5	6	60	51	1.924	2950	110	5
40GDL6-12×6	6	72	51	2.308	2950	110	6
40GDL6-12×7	6	84	51	2.693	2950	110	7
40GDL6-12×8	6	96	51	3.078	2950	110	8
40GDL6-12×9	6	108	51	3.462	2950	110	9
40GDL6-12×10	6	120	51	3.847	2950	110	10
40GDL6-12×11	6	132	51	4.232	2950	110	11
40GDL6-12×12	6	144	51	4.616	2950	110	12
50GDL12-15×2	12	30	56	1.752	2950	118	2
50GDL12-15×3	12	45	56	2.628	2950	118	3
50GDL12-15×4	12	60	56	3.504	2950	118	4
50GDL12-15×5	12	75	56	4.379	2950	118	5
50GDL12-15×6	12	90	56	5.255	2950	118	6
50GDL12-15×7	12	105	56	6.131	2950	118	7
50GDL12-15×8	12	120	56	7.007	2950	118	8
50GDL12-15×9	12	135	56	7.883	2950	118	9
50GDL12-15×10	12	150	56	8.759	2950	118	10
50GDL18-15×2	18	30	62	2.373	2950	123	2
50GDL18-15×3	18	45	62	3.56	2950	123	3
50GDL18-15×4	18	60	62	4.747	2950	123	4
50GDL18-15×5	18	75	62	5.933	2950	123	5
50GDL18-15×6	18	90	62	7.12	2950	123	6
50GDL18-15×7	18	105	62	8.307	2950	123	7
50GDL18-15×8	18	120	62	9.494	2950	123	8
50GDL18-15×9	18	135	62	10.68	2950	123	9
50GDL18-15×10	18	150	62	11.867	2950	123	10
65GDL24-12×2	24	24	65	2.415	2950	120	2
65GDL24-12×3	24	36	65	3.622	2950	120	3
65GDL24-12×4	24	48	65	4.83	2950	120	4
65GDL24-12×5	24	60	65	6.037	2950	120	5
65GDL24-12×6	24	72	65	7.244	2950	120	6
65GDL24-12×7	24	84	65	8.452	2950	120	7
65GDL24-12×8	24	96	65	9.659	2950	120	8
65GDL24-12×9	24	108	65	10.866	2950	120	9
65GDL24-12×10	24	120	65	12	2950	120	10
80GDL36-12×2	36	24	68	3.462	2950	130	2
80GDL36-12×3	36	36	68	5.194	2950	130	3
80GDL36-12×4	36	48	68	6.925	2950	130	4
80GDL36-12×5	36	60	68	8.656	2950	130	5
80GDL36-12×6	36	72	68	10.387	2950	130	6
80GDL36-12×7	36	84	68	12.118	2950	130	7
80GDL36-12×8	36	96	68	13.849	2950	130	8
80GDL36-12×9	36	108	68	15.581	2950	130	9
80GDL36-12×10	36	120	68	17.312	2950	130	10
80GDL54-14×2	54	28	70	5.886	2950	130	2
80GDL54-14×3	54	42	70	8.829	2950	130	3
80GDL54-14×4	54	56	70	11.772	2950	130	4
80GDL54-14×5	54	70	70	14.715	2950	130	5
80GDL54-14×6	54	84	70	17.658	2950	130	6
80GDL54-14×7	54	98	70	20.601	2950	130	7
80GDL54-14×8	54	112	70	23.544	2950	130	8
80GDL54-14×9	54	126	70	26.487	2950	130	9
80GDL54-14×10	54	140	70	29.43	2950	130	10
100GDL72-14×2	72	28	73	7.525	2950	135	2
100GDL72-14×3	72	42	73	11.288	2950	135	3
100GDL72-14×4	72	56	73	15	2950	135	4
100GDL72-14×5	72	70	73	18.814	2950	135	5
100GDL72-14×6	72	84	73	22.576	2950	135	6
100GDL72-14×7	72	98	73	26.339	2950	135	7
100GDL72-14×8	72	112	73	30.1	2950	135	8
100GDL72-14×9	72	126	73	33.86	2950	135	9
100GDL72-14×10	72	140	73	37.63	2950	135	10
